Features:
1. Mobile metering, taking and feeding, single range 0-150kg, viscosity: 0-5000mPa.s, feeding port can be equipped with high-pressure spray device.
2. Metering device: optional imported high-precision gear pump, rotor pump, etc., equipped with servo control speed regulation, no pulse, stable flow, corrosion resistance;
3. Electronic scale: Toledo high-precision electronic scale is selected, and the display division is 1-10g.
4. Measurement accuracy: <30kg is ±5g, <150kg is ±10g.
5. The storage tank is equipped with oil-electric heating, and the filling pipeline and the delivery pump are insulated by electric heating, which is suitable for materials that are easy to crystallize and solidify and agglomerate at low temperature.
6. Professional food-grade design, storage tanks, pumps, valves, pipe fittings, etc. can be selected in line with FDA certification, and the system connection design is easy to clean and easy to drain.
7. The PLC and touch screen adopt internationally renowned brands (such as Siemens, Schneider), the power supply adopts single-phase 380V/220V, 50Hz, and the voltage of all other instruments adopts 24V; optional explosion-proof design.
